Rated voltage | kV | 12 | 24 | |
Rated insulation level | Power frequency withstand voltage (1min) | kV | 42/48 | 65/79 |
Lighting impulse withstand voltage (peak) | kV | 75/85 | 125/145 | |
Rated current | A | 630-4000 | 630-3150 | |
Rated short-time withstand current | kA | 25-40 | 25-40 | |
Rated peak withstand current | kV | 63-100 | 63-100 | |
Rated short-circuit breaking current | kA | 25-40 | 25-40 | |
Rated short-circuit making current | kA | 63-100 | 63-100 | |
Rated frequency | Hz | 50 | 50 | |
Secondary circuit rated short-time withstand voltage（1min） | kV | 2 | 2 | |
Secondary circuit rated voltage | V | DC110、220 / AC110、220 | DC110、220 / AC110、220 |
